Power Puck® II Radiometer / UviCure Plus® II

EIT 2.0™ UviCure® Plus II — Single-Band Industrial UV Radiometer for Precise Dose & Intensity Measurement

The EIT 2.0 UviCure® Plus II (SAL-B1014 Rev 01.00) is a high-performance, single-band UV radiometer engineered to deliver quantitative, portable measurement of UV irradiance and energy density in demanding industrial curing environments. With EIT’s proven optical and electronic design heritage, UviCure Plus II provides operators, engineers, and quality teams with objective, repeatable data for process verification, diagnostic comparison, and UV system control.

Technical Performance & Measurement Authority

• Single-Band Continuous Monitoring: Configurable to monitor one spectral bandwidth — **UVA (320–390 nm), UVB (280–320 nm), UVC (250–260 nm), UVV (395–445 nm), or optional UVA2 (380–410 nm) for LED and additive bulbs — selected at time of order.

• High-Resolution Dose & Intensity: Simultaneously displays peak irradiance (W/cm²) and total energy density (J/cm²) in a range of user-selectable units (µW/cm² to W/cm²; µJ/cm² to J/cm²) for clear engineering interpretation.

• Suggested Operating Ranges: Optimized dynamic ranges support high-power curing up to 10 W/cm² (standard) and tailored mid or low-power ranges for non-focused lamps or distant exposures, ensuring fidelity across diverse UV sources.

• Advanced Sampling Modes: Adjustable effective sample rates — Smooth ON (25 Hz), Smooth PROFILER (128 Hz), Smooth OFF (2048 Hz) — enable accurate capture of irradiance peaks and temporal dynamics across slow and fast cure cycles.

Rugged, Field-Ready Engineering

• Compact, Lightweight Form: At ~117 mm diameter × 12.7 mm thick, UviCure Plus II inserts directly into most UV curing zones without process disruption.

• Durable Build: Aluminum and stainless-steel construction with cosine-approximate spatial response and an easy-to-read, high-contrast display supports harsh UV environments.

• Battery-Powered Portability: Two user-replaceable AAA cells deliver ~20 hours of operation, enabling extended on-floor use without external power.

• USB Data Communication: Integrated cable interface allows transfer of measurement results to PC for logging, trending, and process documentation with UV PowerView® software.

Solution-Oriented Benefits for UV Process Control

The UviCure Plus II is engineered for industrial teams requiring repeatable, quantitative control of UV curing systems, including:

• Cure Verification & Baseline Establishment: Objective measurement replaces guesswork with calibrated irradiance and dosage values.

• Performance Trending & Comparison: Reference mode enables direct side-by-side comparison of current UV output against baseline runs to detect lamp aging or reflectivity loss.

• Process Repeatability: Consistent data capture supports quality systems, helping maintain tight tolerances for inks, coatings, adhesives and specialty materials.

By combining precise metrology, rugged industrial design, and flexible data capture, the UviCure Plus II radiometer empowers engineers and operators to optimize UV curing performance and maintain measurable control across production environments.
